5pcs 12mm High Head Momentary Push Button Switch 12V-24V (ON)-Off 4Pins Normally Open Waterproof Silver Metal Shell for 1/2" Mounting Hole with Pre-soldered Cable Halo Ring Red LED
Product details
| Management number | 236843499 | Release Date | 2026/07/10 | List Price | $5.06 | Model Number | 236843499 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- Momentary: Press the button and hold-ON, Release-OFF; High Round Raised Cap for easy operation; Electrical life: 100, 000 times, Mechanical life: 500,000 cycles
- Mounting Hole: 12mm(1/2"); Shell Material: Nickel Plated Brass; LED Light: 2A 12V-24V Halo Ring; LED Life: 40, 000 hours
- 2 wiring methods: LED light can be always on, or illuminates when the device is working; each switch is equipped with s pre-wired socket for easy connecting
- Protection Degree: IP66 Waterproof and dustproof; IK09 Anti-vandal rate. It can be used in wet or dusty environment; But Don’t immerse the button switch in water
- Wide Applications: Suitable for car, computer, instrument and meter industry, door bell, home appliance etc.
| ASIN | B0GTK8M5VM |
|---|---|
| Color | Red |
| Brand Name | DMWD |
| Unit Count | 5.0 Count |
| Part Number | AN12-TDNGT-HXZF-HX15cm-R-5Ge |
| Manufacturer | DMWD |
| Material Type | Metal |
| Connector Type | Quick Connect |
| Current Rating | 2 Amps |
| Operation Mode | ON-OFF |
| Item Dimensions | 7.09 x 0.55 x 0.55 inches |
| Operating Voltage | 12 Volts (DC) |
